Redi-Mate™ 1P

Description

Onanon’s Redi-Mate™ 1P Series is a highly configurable plastic push-pull connector. The push-pull latching system is simple and quick, yet safe and reliable for frequent connection/disconnection through harsh environments. The ergonomic design has been field tested and is approved for Medical applications. Additional suitable markets include but are not limited to the automotive, aerospace and industrial industries. Redi-Mate™ has a large selection of insert configurations (high-density low voltage, high voltage, coaxial, fluidic, and hybrid). Redi-Mate is backwards compatible to similar push-push pull connectors.
  • 2-14 pin capacity
  • Security of Push-Pull, self-latching system
  • Customizable for reusable or single use applications
  • Customizable color, conical nuts and keying to prevent mismatching
  • Easily add components such as EEPROMs, resistors and capacitors

Resources

Item Resources

3D Reference CAD
  • Inline Receptacle
  • Panel Mount Receptacle
  • Plug
