MagConnect® | Hero

Description

Onanon’s MagConnect®| Hero is performance engineered to be the most intuitive interconnect in the world. Its unique magnetic safety latch feature is ideal for medical applications, where time, precision, and quality are most critical. Additional suitable markets include but are not limited to the automotive, aerospace and industrial industries. MagConnect® series has been used in applications with low & high voltages, sensitive EMI, shock & vibration environments, and integration of intelligent electronics.
  • 2 to 20 pin capacity
  • Intuitive and self-mating
  • Magnetic safety de-latching
  • Customizable for reusable or single use applications
  • Easily add components such as EEPROMs, resistors and capacitors
  • EMI/RFI Safe
  • Low (<12v) & High (>5000v) Voltage Safe
  • Rugged use in outdoor wearables • VF/HF/RF Safe

Pricing

Distributor SKU Description Stock Min Pkg Currency 1 10 100 Updated
Digikey 193-A001-20S-U280-W MagConnect®| Hero Plug Kit 0 1 Each USD 67.620 57.475 48.864 Dec 3, 2025
Digikey 193-A002 MagConnect®| Hero Receptacle 21 1 Each USD 81.110 68.948 58.618 Dec 3, 2025
Mouser 193-A002 MagConnect®| Hero Receptacle 177 1 Each USD 71.120 62.140 58.610 Dec 3, 2025
Mouser 193-A001 MagConnect®| Hero Plug Kit 176 1 Each USD 58.570 49.270 41.970 Dec 3, 2025

Resources

Item Resources

3D Reference CAD
  • Inline Receptacle
  • Panel Mount Receptacle
  • Plug
